Boosting Efficiency with High-Performance Extruded Fin Tubes
When our client from Singapore approached us, they faced a critical challenge: their existing heat exchange equipment was inefficient, leading to escalating energy consumption and higher operational costs. They needed a solution that could maximize heat transfer within their current system constraints.
The Solution
We provided a custom-engineered batch of High-Performance Extruded Fin Tubes. This design was selected for its superior heat transfer capabilities and durability, specifically tailored to replace their underperforming components.
The Solution: Precision-Engineered Extruded Finned Tubes
Our technical department analyzed the client’s thermal requirements and selected an Extruded Aluminum-Steel configuration. Unlike wrap-on fins, our extruded process creates a high-pressure mechanical bond, ensuring 100% surface contact and permanent heat transfer efficiency.
Technical Specifications
| Component | Specification |
| Base Tube Material | Seamless Stainless Steel TP304L |
| Base Tube Size | 26.7 mm x 2.87 mm |
| Fin Material | Aluminum 1060 (High Thermal Conductivity) |
| Fin Dimensions | OD 52.7 mm |
| Fin Thickness | 0.3 mm |
| Fin Pitch | 2.31 mm |
| Unfinned Length | 80/80 mm |
- Product Type: Extruded Finned Tubes
- Base Tube Size: 26.7mm OD × 2.87mm Thickness
- Base Material: Seamless TP304L (Stainless Steel)
- Fin Material: Aluminum 1060
- Fin Dimensions:
- Outer Diameter: 52.7mm
- Thickness: 0.3mm
- Pitch: 2.31mm
- Configuration: Unfinned length 80mm at both ends (80/80mm)
Seamless TP304L Extruded Finned Tubes
The Datang Service Difference
At Datang, we believe that industrial manufacturing is a service-driven industry. This project highlights our core service pillars:
- Proactive Technical Consulting: We don’t just take orders; we verify specifications. Our engineers worked closely with the Singapore team to ensure the TP304L/AL1060 combination was the most cost-effective solution for their specific environment.
- The “Datang Speed” Guarantee: In the energy sector, every day of downtime is lost revenue. By optimizing our internal supply chain and production scheduling, we compressed the timeline from initial inquiry to final delivery into just 20 days.
- Rigorous Quality Control: Every tube in this batch underwent strict dimension checks and fin-to-tube bond testing to ensure that the “zero-decay” heat transfer promise is kept for years to come.
-
Global Logistics Coordination: Navigating international shipping can be complex. Datang handled the documentation and logistics to ensure the cargo arrived in Singapore on time and ready for immediate installation.
Result & Impact
The installation of Datang’s high-performance tubes led to a measurable increase in heat transfer coefficients. The client reported a significant reduction in operational energy consumption and a stabilized thermal output, proving that the right components—delivered at the right time—are the best investment for long-term sustainability.
By partnering with Datang, the Singaporean client not only resolved their immediate heat exchange challenges but also achieved dual wins in cost reduction and environmental sustainability. This successful collaboration reaffirms our position as a trusted provider of customized heat transfer solutions, and we remain committed to delivering exceptional value to clients worldwide through innovation, expertise, and unparalleled efficiency.
Partner with Datang Finned Tube
Whether you are retrofitting an existing system or designing a new project, our team provides the technical expertise and manufacturing speed your business demands.
Contact us today for a professional consultation.
