Finned Tube Serrated Machine
Finned tube serrated machine is mainly used to process a specific serrated structure on the surface of the finned tube to enhance the heat transfer efficiency or adapt to the subsequent installation requirements.
- Motor power: 75KW
- Steel belt serrated linear speed: 0~50M/min
- Serrated width: Customize
- Serrated depth: Customize
Finned Tube Serrated Machine Function
High Frequency Welding Serrated: The surface of the finned tube is heated by high frequency current to make it plastic and then rolled to form. It is suitable for the processing of spiral finned tubes made of carbon steel and stainless steel.
Weldless Design: The hot rolling process is used to achieve integrated forming of the fin and the base tube, improving the pressure bearing capacity and wear resistance.
Finned Tube Serrated Machine Application Field
It is mainly used in boiler economizers, air preheaters, chemical heat exchange equipment and other scenarios. It has the characteristics of high heat transfer efficiency and low flow resistance.
- Datasheet
- Drawing
- Certificates
Finned Tube Serrated Machine Technical Parameters
| Parameter | Specification |
|---|---|
| Motor power | 75KW |
| Serration line speed | 0～50 meters per minute |
| Serration width | Customizable per customer request |
| Serration depth | Adjustable (typically 50mm-18mm) |
| Fin material | Stainless steel/carbon steel |
| Stainless steel fin thickness | 1.5mm |
| Stainless steel fin width | 25mm |
| Carbon steel fin thickness | 2mm |
| Carbon steel fin width | 25mm |
Serrated Fin Tube Produced by Finned Tube Serrated Machine
Structural features of Finned Tube Serrated Machine
This serrated machine mainly consists of a speed regulating motor, a reduction gearbox, a gearbox, a cooling system, etc. It has a compact structure, is easy to install and debug, has a large starting torque of the motor, and is balanced when starting.
Finned Tube Serrated Fins
Specific parameters of the serrated machine are as follows:
(1) Motor power is 75KW.
(2) Steel belt serrated linear speed is 0~50M/min.
(3) Serrated width: set according to user requirements. (4) The serrated depth can be adjusted according to the customer’s requirements. (Generally 50mm-18mm)
(5) Fin material: stainless steel and carbon steel (stainless steel fin thickness 1.5mm width 25mm; carbon steel fin thickness 2mm width 25mm)
Finned Tube Serrated Machine Packaging
Finned tube serrated machine will be bare loaded in two 40′ GP containers.
Port
Finned tube serrated machine rroduction line will be shipped from Tianjin Port,China
Lead time:
Quantity(sets) 1-1 >1
Lead time (days) 60 To be negotiated
